6mm Ultra-Thin Silicon Carbide Ceramic Tile with NIJ Level III Protection and High Density Microstructure
商品の詳細:
| 起源の場所: | 湖南省、中国 |
| ブランド名: | High Broad |
| 証明: | ISO 9001:2015, NIJ 0101.06 |
| モデル番号: | シックタイル |
| 書類: | SIC Ballistic Armor Tiles-P...ad.pdf |
お支払配送条件:
| 最小注文数量: | 1000個 |
|---|---|
| 価格: | USD 0.1-1 / Piece |
| パッケージの詳細: | 個別の EPE フォームインサート + 真空密封された帯電防止バッグ + 輸出用合板ケース |
| 受渡し時間: | 在庫に5〜7営業日、生産に15〜20日 |
| 支払条件: | T/T、L/C、ウェスタンユニオン |
| 供給の能力: | 1 か月あたり 2500,000 個 |
|
詳細情報 |
|||
| 密度: | 3.12～3.18 g/cm3 | 硬度(GPa): | 25-28 |
|---|---|---|---|
| 曲げ強度: | 400～480MPa | タイルのサイズ: | 100x100mm |
| 面積密度: | ≤28kg/㎡ | 破壊靱性: | 3.8～4.8MPa・m1/2 |
| ハイライト: | Ultra Thin SiC Tile,Lightweight Strike Face Plate,NIJ III Thin Armor Ceramic |
||
製品の説明
- 6mm Ultra-Thin Profile
- High Density Microstructure
The HB achieves NIJ Level III protection with just 6mm ceramic thickness—a 25% reduction from standard 8mm tiles. This is made possible through our advanced high-density pressureless sintering process that produces SiC with 3.15+ g/cm³ density and 2600+ HV hardness, approaching hot-pressed density values without the associated cost premium. The result: armor systems that are significantly lighter and thinner without compromising protection.
| Ceramic Type | Required Thickness | Areal Density @ NIJ III | Weight Index |
|---|---|---|---|
| HB SiC (6mm high-density) | 6.0 mm | ≤ 28 kg/m² | ★★★ Best |
| Standard SiC (8mm) | 8.0 mm | ~36 kg/m² | ★★ Good |
| Alumina Al2O3 (10mm) | 10.0 mm | ~42 kg/m² | ★ Heavy |
| Boron Carbide B4C (6mm) | 6.0 mm | ~22 kg/m² | ★★★★ Lightest (High Cost) |
WNRLN 6mm SiC achieves the optimal balance: B4C-level thinness at 50-60% lower cost.
Our controlled-atmosphere pressureless sintering process achieves 98.5%+ theoretical density with minimal porosity (<0.5%), enabling the thinner profile without strength compromise.
The 6mm ultra-thin profile and 28 kg/m² areal density make this tile ideal for helicopter crew seats, vehicle spall liners, and portable shield applications where weight budget is critical.
Double-side ground to ≤20μm flatness and ≤0.8μm Ra surface finish, ensuring uniform adhesive bond line thickness across the entire tile surface.
Despite the thin profile, enhanced fracture toughness (3.8-4.8 MPa*m½) ensures reliable multi-hit performance. Tested with 3-round triangular shot pattern at 50mm spacing.
Technical datasheets and ballistic test reports available
