Universal Boron Carbide Sandblasting Nozzle for High Efficiency Blasting with Extended Service Life
商品の詳細:
| 起源の場所: | 湖南省、中国 |
| ブランド名: | High Broad |
| 証明: | ISO 9001:2015 |
| モデル番号: | HB-200X11mm |
| 書類: | Venturi nozzle Jane.pdf |
お支払配送条件:
| 最小注文数量: | 10個 |
|---|---|
| 価格: | USD 70.00 - 100.00 / Piece |
| パッケージの詳細: | 個別のフォーム裏地付きボックス、防湿性のある輸出グレードの段ボール箱 |
| 受渡し時間: | 在庫に3〜5営業日、生産に15〜20日 |
| 支払条件: | T/T、L/C、ペイパル、ウェスタンユニオン |
| 供給の能力: | 月あたり 50,000 個 |
|
詳細情報 |
|||
| ノズルの種類: | ベンチュリボア | 硬度: | ≥2800 ヌープ (香港) |
|---|---|---|---|
| 穴径: | 11mm | ノズル材質: | 炭化ホウ素 (B4C) |
| 接続スレッド: | M16×1.5 | ノズルの長さ: | 200mm |
| ハイライト: | Universal Abrasive Compatible,High Efficiency Sandblast,Multi Purpose Boron Carbide |
||
製品の説明
Key Advantages
Universal Abrasive Compatibility
Optimized bore geometry and B4C material compatibility with aluminum oxide, silicon carbide, garnet, steel grit, glass beads, and walnut shell. Switch abrasives without changing nozzles.
High Efficiency Blasting
50mm extended venturi with 9mm large bore accelerates abrasive media to maximum velocity. Achieves up to 25 m²/hr material removal rate, significantly reducing project turnaround time.
Extended Service Life
B4C ceramic with Knoop hardness ≥2800 HK withstands the abrasive wear of even the most aggressive media like silicon carbide and steel grit for thousands of operating hours.
Cost-Effective Multi-Purpose
Replace multiple specialized nozzles with one universal solution. Reduce inventory complexity and procurement costs while maintaining top-tier blasting performance across all media types.
Technical Specifications
| Material | Boron Carbide (B4C) Ceramic |
| Nozzle Type | Venturi Bore |
| Bore Diameter | 11mm |
| Nozzle Length | 200mm |
| Material Removal Rate | Up to 25 m²/hr |
| Compatible Abrasives | Al₂O₃, SiC, Garnet, Steel Grit, Glass Beads, Walnut Shell |
| Hardness | ≥2800 HK (Knoop) |
| Max Operating Pressure | 0.8 MPa (116 PSI) |
Applications
- Heavy steel structure and bridge surface preparation
- Shipyard hull blasting with multiple abrasive media types
- Industrial tank and pressure vessel interior/exterior blasting
- Concrete surface profiling and coating removal
- Multi-project job shops requiring abrasive flexibility
Contact US:
China Hunan High Broad New Material Co., Ltd.
70 Chezhan North Road,Changsha, China 410100
Tel:+86-731-85717705
Fax:+86-731-85716569
Mobile/Whatsapp: +86-139-7515-2932
Simplify your blasting operations with one universal nozzle. Contact us for bulk pricing and OEM customization options today.
