99.999% Purity Yttrium Oxide Powder (Y2O3) for Thermal Spray Grade Plasma Resistant Coating in Semiconductor Chambers
商品の詳細:
| 起源の場所: | 江西、中国 |
| ブランド名: | High Broad |
| 証明: | ISO 9001:2015, REACH |
| モデル番号: | Y2O3-5N |
お支払配送条件:
| 最小注文数量: | 1000キログラム |
|---|---|
| 価格: | USD 5-100 / Kilogram |
| パッケージの詳細: | 真空密封された内袋とアルミホイルの外袋、25kgのファイバードラムに梱包、または顧客の要件に応じて梱包 |
| 受渡し時間: | 注文確認後5〜15営業日 |
| 支払条件: | T/T、L/C、ペイパル、ウェスタンユニオン |
| 供給の能力: | 1ヶ月あたりの500000キログラム |
|
詳細情報 |
|||
| 密度: | 5.01g/cm3 | 比表面積: | 8-15m²/g |
|---|---|---|---|
| 粒子サイズ: | 1〜5 μm | 融点: | 2425 °C |
| 結晶構造: | キュービック | 純度: | 99.999% (5N) |
| ハイライト: | 5N Yttrium Oxide Powder,Thermal Spray Coating Grade,Semiconductor Chamber Protection |
||
製品の説明
99.999% (5N) Yttrium Oxide (Y₂O₃) Thermal Spray Grade Powder
Our 99.999% (5N) yttrium oxide powder is manufactured in China using advanced rare earth extraction and purification technology. This thermal spray grade Y₂O₃ powder is specifically engineered for thermal spray coating of semiconductor chamber components, delivering exceptional consistency and performance in demanding industrial coating environments.
Key Features
- Ultra-high 99.999% (5N) purity for minimal contamination in sensitive semiconductor processes
- Optimized particle size distribution (1-5 μm D50) for consistent thermal spray deposition
- Excellent plasma etch resistance extends chamber component service life by 3-5x
- High melting point (2425°C) ensures coating stability under extreme thermal cycling
- Low impurity levels of Fe, Na, Ca, Si ensure coating purity and dielectric integrity
Technical Specifications
| Parameter | Specification |
|---|---|
| Purity | 99.999% (5N) |
| Particle Size D50 | 1-5 μm |
| Crystal Structure | Cubic |
| CAS Number | 1314-36-9 |
| Appearance | White Powder |
| Density | 5.01 g/cm³ |
| Melting Point | 2425 °C |
| Specific Surface Area | 8-15 m²/g |
Recommended Applications
This yttrium oxide powder is widely used in thermal spray coating, plasma spray deposition, ceramic surface treatment, and other industrial coating processes requiring high purity rare earth materials. Its excellent thermal stability, chemical resistance, and plasma etch resistance make it ideal for protective coatings in harsh operating environments.
Packaging & Storage
Vacuum sealed inner bag with aluminum foil outer layer to prevent moisture absorption. Packed in 25kg fiber drums with desiccant. Store in a cool, dry place away from acids and moisture.
